Two Component Cantilever Glue Machine
Quick Detail:
1. Cantilever Design: Unique overhead structure for unobstructed access to extra-large panels.
2. Super-Sized Capacity: Handles panels up to 3M (W) x 17M (L) x 120MM (T).
3. Wide Coating Range: Adjustable coating width from 1000mm to 3000mm (Optional).
4. Heavy-Duty Bonding: Designed for two-component adhesives in demanding RV and truck applications.
5. Precision for Large Areas: Maintains ≤ ±5% flow accuracy even on vast surfaces.
6. Robust Power: 10KW system built for continuous industrial operation.
Description:
The LY-05-1300 Two-Component Cantilever Glue Dispensing Machine is engineered for the heavy-duty composite needs of the transportation industry. Its innovative cantilever design allows the glue head to traverse over the entire surface of exceptionally large and long panels—such as RV sidewalls and refrigerated truck bodies—without floor obstructions, facilitating easy loading and unloading. This machine delivers precise, uniform adhesive application across widths up to 3 meters, ensuring strong, reliable bonds for critical composite structures. It is the ideal solution for manufacturers requiring robust and efficient glue dispensing for oversized panel lamination.
Specifications:
|
Technical Parameter
|
Specification
|
|
Model Number
|
LY-05-1300
|
|
Work Coating Amount
|
500 - 4000 g/min
|
|
Adhesive Flow Accuracy
|
≤ ±5%
|
|
Glue Nozzle Hole Interval
|
8mm
|
|
Coating Width Range
|
1000 - 3000 mm (Optional)
|
|
Max. Production Line Speed
|
6 m/min
|
|
Glue Application (Unit Area)
|
200 - 500 g/m² (Total ≤ 4000 g/min)
|
|
Adhesive Viscosity Range
|
Up to 25,000 mPa.s
|
|
Adhesive Type
|
Two-Component
|
|
Applicable Board Specs (W x L x T)
|
1-3 M (W) x 1-17 M (L) x 2-120 MM (T)
|
|
Air Supply
|
0.6 - 0.8 MPa
|
|
Power Supply
|
380V, 50Hz, 3-Phase (Optional)
|
|
Max. Power
|
10 KW
|
Notices:
1. The cantilever design requires sufficient overhead clearance and a stable foundation.
2. Due to the large panel size, ensure your factory layout accommodates the length of up to 17 meters for panel handling.
3. Regular inspection of the cantilever rail and movement mechanism is recommended for long-term precision.
Applications:
Specifically built for the lamination of extra-large, reinforced panels in the transportation and specialty vehicle sectors:
1. RV (Recreational Vehicle) Cabin Panels and Sidewalls
2. Refrigerated Truck and Trailer Body Panels
3. Large-format Industrial and Architectural Composite Panels
