Three-Layer Hot Press Machine
Specifications:
|
Technical Parameter
|
Specification
|
|
Model Number
|
LY-11-1000T
|
|
Main Application
|
Hot press lamination of SPC to wood, insulation boards, door cores
|
|
Applicable Board Width
|
0.5 - 1.3 m (Customizable)
|
|
Applicable Board Length
|
1 - 3 m
|
|
Applicable Board Thickness
|
10 - 120 mm (Customizable)
|
|
Equipment Length
|
10 m (Customizable)
|
|
Press Opening Distance
|
200 mm (Customizable)
|
|
Productivity
|
Approx. 2 pieces per minute (Glue dependent)
|
|
Heating Temperature Range
|
Room Temperature to 120°C (Adjustable)
|
|
Press Pressure
|
Up to 100 Tons (Optional)
|
|
Power Supply
|
380V 50Hz 3-Phase (Optional)
|
|
Max. Power Consumption
|
200 KW
|
|
Air Source Requirement
|
0.6 - 0.8 MPa
|
Quick Detail:
1. Continuous Through-Feed Design: Enables non-stop feeding and discharging for high-volume production.
2. Three Independent Press Layers: Allows simultaneous pressing of multiple panels, tripling output in the same footprint.
3. High Pressure & Heat: Delivers up to 100 tons of pressure and adjustable heat up to 120°C for strong, rapid bonding.
4. For Multi-layer Composites: Ideal for laminating SPC to wood, insulation boards, and door cores under heat and pressure.
5. Heavy-Duty Construction: Robust 10-meter long frame built for continuous industrial operation.
Applications:
The ultimate solution for high-volume, heat-activated lamination:
1. Ecological Door Production: Final hot-pressing of laminated door slabs (e.g., SPC face + wood core).
2. Decorative/Wall Panel Manufacturing: Bonding decorative surfaces (SPC, HPL) to substrate boards under heat and pressure.
3. Furniture Panel Production: Manufacturing flat, sturdy composite panels for cabinets and tables.
