Two-Component Curtain Coating Equipment
Quick Detail:
1. Dual-Component System: Designed for precision metering and mixing of two-component adhesives.
2. High-Speed Curtain Coating: Work coating capacity from 500 to 4000 g/min.
3. Excellent Accuracy: Adhesive flow accuracy within ±5%.
4. Wide & Adaptive: Coating width range 100-1300mm (optional auto-width recognition).
5. For Rigid Panels: Ideal for honeycomb, SPC composite, door, and automotive panels.
6. Powerful & Customizable: Standard length 10m (customizable), robust 10KW power system.
Description:
The LY-02-1300 Automatic Two-Component Curtain Coating Equipment is a professional solution for high-strength panel lamination. It expertly meters, mixes, and applies two-component adhesives in a uniform curtain, perfectly suited for bonding honeycomb cores, SPC composites, and other industrial panels. The system ensures consistent mix ratio and glue application, resulting in superior bond strength and product durability. With its optional automatic width recognition and high-capacity design, it seamlessly integrates into automated lines, significantly boosting productivity and quality in composite panel manufacturing.
Specifications:
|
Technical Parameter
|
Specification
|
|
Model Number
|
LY-02-1300
|
|
Work Coating Amount
|
500 - 4000 g/min
|
|
Adhesive Flow Accuracy
|
≤ ±5%
|
|
Glue Nozzle Hole Interval
|
8mm
|
|
Coating Width Range
|
100 - 1300 mm (Auto-recognition Optional)
|
|
Max. Production Line Speed
|
15 m/min
|
|
Glue Application (Unit Area)
|
120 - 400 g/m² (Total ≤ 4000 g/min)
|
|
Adhesive Viscosity Range
|
Up to 25,000 mPa.s
|
|
Adhesive Type
|
Two-Component
|
|
Equipment Length (Standard)
|
10 m (Customizable)
|
|
Air Supply
|
0.6 - 0.8 MPa
|
|
Power Supply
|
380V, 50Hz, 3-Phase (Optional)
|
|
Max. Power
|
10 KW
|
Applications:
Ideal for the lamination process in the production of:
1. Honeycomb Panels (e.g, for doors, partitions)
2. SPC (Stone Plastic Composite) Panels
3. Door and Automotive Interior Panels
4. Building Insulation Wall Panels
5. Other composite panel structures requiring high-strength bonds.
