Single-Component Glue Spraying Machine
Quick Detail:
1. High-Speed Coating: Work coating amount from 500 to 4000 g/min.
2. Precision Control: Adhesive flow accuracy within ±5%.
3. Wide Adaptability: Coating width range 100-1300mm, automatically adjustable.
4. High Efficiency: Compatible with production line speeds up to 15m/min.
5. Simplified Process: Designed for single-component adhesives (viscosity below 25,000 mPa.s).
6. Robust Design: Standard length 6m (customizable), power up to 7KW.
Description:
The LY-01-1300 Automatic Single Component Glue Dispensing Machine is engineered for precision and efficiency in industrial panel coating. It excels in applying single-component adhesives uniformly across large surfaces such as door panels, automotive interior panels, and building insulation wall panels. Its intelligent system automatically identifies the product width for seamless adaptation, ensuring consistent glue application while maximizing production line speed up to 15m/min. Built for reliability and ease of integration, it's the ideal solution to automate your bonding process, reduce material waste, and enhance product quality.
Specifications:
|
Technical Parameter
|
Specification
|
|
Model Number
|
LY-01-1300
|
|
Work Coating Amount
|
500 - 4000 g/min
|
|
Adhesive Flow Accuracy
|
≤ ±5%
|
|
Glue Nozzle Hole Interval
|
17mm
|
|
Coating Width Range
|
100 - 1300 mm (Auto-recognition)
|
|
Max. Production Line Speed
|
15 m/min
|
|
Glue Application (Unit Area)
|
100 - 400 g/m² (Total ≤ 4000 g/min)
|
|
Adhesive Viscosity Range
|
Up to 25,000 mPa.s
|
|
Adhesive Type
|
Single-Component
|
|
Equipment Length (Standard)
|
6 m (Customizable)
|
|
Air Supply
|
0.6 - 0.8 MPa
|
|
Power Supply
|
380V, 50Hz, 3-Phase (Optional)
|
|
Max. Power
|
7 KW
|
Notices:
1. Ensure the air supply is stable and meets the required pressure (0.6-0.8 MPa) before operation.
2. Use only single-component adhesives within the specified viscosity range (≤ 25,000 mPa.s) for optimal performance.
3. Regular maintenance of the glue nozzle is recommended to prevent clogging.
Applications:
Primarily used for the automated glue application process in manufacturing:
1. Door and Door Panels
2. Automotive Interior Panels and Trim
3. Building Insulation Wall Panels
4. Other large-format panel laminating industries.
